Combi Tool PCT50
Cordless Combi Tool, part of the Holmatro Pentheon Series. Designed to offer you the unrestrained performance, unparalleled speed and ultimate control you’ve never experienced before!
Description
Cordless Combi Tool, part of the Holmatro Pentheon Series. Designed to offer you the unrestrained performance, unparalleled speed and ultimate control you’ve never experienced before!
| Details | ||
| Articlenumber | 151.000.529 | |
| Basic specifications | ||
| model | PCT50 | |
| max. working pressure | 720 / 72 (bar/Mpa) | 10443 psi |
| battery included | no | |
| Performance | ||
| max. spreading force | 1860 / 189.7 (kN/t) | 418145 lbf |
| min. spreading force (EN 13204) | 43 / 4.4 (kN/t) | 9667 lbf |
| spreading distance | 380 mm | 15 in |
| max. cutting opening | 320 mm | 12.6 in |
| max. squeezing force | 87 / 8.9 (kN/t) | 19558 lbf |
| max. pulling force | 104 / 10.6 (kN/t) | 23380 lbf |
| protection rate | IP57 | |
| directives | 2006/42/EC, 2014/30/EU | |
| theoretical cutting force | 670 / 68.3 (kN/t) | 150622 lbf |
| Dimensions, weight and temperature | ||
| weight, ready for use | 20.3 kg | 44.8 lb |
| weight excl. battery | 18.8 kg | 41.4 lb |
| dimensions (AxBxC) | 898 x 268 x 273 mm | 35.4 x 10.6 x 10.7 in |
| Norms | ||
| EN 13204 classification | CK43/380J-20.3 | |
| NFPA 1936, cutting capacity | A7 B8 C8 D8 E8 F3 | |
| NFPA 1936 compliant | yes | |
| EN 13204, cutting capacity | 1J 2J 3K 4K 5K | |
| EN 13204 compliant | yes | |
| NFPA 1936, HPF | 104 / 10.6 (kN/t) | 23380 lbf |
| NFPA 1936, HSF | 42.5 / 4.3 (kN/t) | 9554 lbf |
| NFPA 1936, LPF | 79.7 / 8.1 (kN/t) | 17917 lbf |
| NFPA 1936, LSF | 32.9 / 3.4 (kN/t) | 7396 lbf |
| Cutting performance | ||
| round bar (S235 acc. to EN 13204) | 36 mm | 1.4 in |
Specifications:
