Door Ram DR200ST

Double-acting door ram with a CORE hose connection.
Designed for breaching inward opening doors with multiple locks. Also suitable for outward opening doors, when used in combination with a manual breaching tool.

Description

Specifications:

Item Description
SPECIFICATIONS
Details
Articlenumber 151.001.346
Basic specifications
model DR200ST
equipped with (connector type) CORE
max. working pressure 720 / 72 (bar/Mpa) 10443 psi
Performance
spreading force over full stroke 71 / 7.2 (kN/t) 15961 lbf
spreading stroke 300 mm 11.8 in
retracted length 597 mm 23.5 in
extended length 897 mm 35.3 in
directives 2006/42/EC
Dimensions, weight and temperature
weight, ready for use 7.6 kg 16.8 lb
dimensions (AxBxC) 112 x 597 x 160 mm 4.4 x 23.5 x 6.3 in
FEATURES

Highly capable

  • Thanks to a long spreading stroke even the most flexible doors can be opened
  • Unlike combi tool style door openers the door ram has a constant high spreading force over its full stroke, to provide full power where you need it

Ease of placement

  • With its small toe height the door ram can be easily inserted into the door frame

Enhanced safety for the operator

  • The toe is attached at a 90-degree angle to the tool body, so you need not be in front of the door to operate the tool. You can work from a position next to the door, out of harm’s way

One person operation when used with our backpack pump

  • No need to carry and operate a separate hand pump

Compact and lightweight

  • Easy to carry and handle
