Door Ram GDR200STEVO3

Double-acting cordless door ram powered by EVO3 battery technology for breaching inward opening doors with multiple locks. Also suitable for outward opening doors, when used in combination with a manual breaching tool.

Description

Specifications:

Item

Description

SPECIFICATIONS

Details
Articlenumber	151.001.491
Basic specifications
model	GDR200STEVO3
max. working pressure	720 / 72 (bar/Mpa)	10443 psi
battery included	no
Performance
spreading force over full stroke	71 / 7.2 (kN/t)	15961 lbf
spreading stroke	300 mm	11.8 in
retracted length	728 mm	28.7 in
extended length	1028 mm	40.5 in
protection rate	IP54
directives	2006/42/EC, 2014/30/EU
General specifications
operator type	battery
Dimensions, weight and temperature
weight, ready for use	13.4 kg	29.5 lb
weight (excl. battery)	12.4 kg	27.3 lb
dimensions (AxBxC)	193 x 728 x 277 mm	7.6 x 28.7 x 10.9 in

FEATURES

Self contained

Cordless thanks to the use of our existing EVO 3 battery technology: No external pump and hose(s) needed.

Highly capable

Thanks to a long spreading stroke even the most flexible doors can be opened
Unlike combi tool style door openers the Door Ram has a constant high spreading force over its full stroke to provide full power where you need it.

Ease of placement

With its small toe height the Door Ram can be easily inserted into door frame

Safe to use in harsh environments

Thanks to IP 54 rating: Protection against dust and splashing of water

Enhanced safety for the operator

The toe is attached perpendicular (at a 90-degree angle) to the tool body allowing the operator not to stand in front of the door. The operator can work from a position next to the door, out of harms way.
