Door Blaster HDB 90 ST

Door opener for extremely fast door breaching. Designed for quiet and remote operation.

Standard supplied with:
• Round pushing plate DBP 12
• Rectangular pushing plate DBP 14
• Extension piece DBE 01
• Extension piece DBE 02
• Extension piece DBE 03
• Grip head DBH 21, set of 2
• Grip head DBH 23, set of 2
• Grip head DBH 24, set of 2
• Carrying / storage bag DBC 01

Description

Specifications:

Item

Description

SPECIFICATIONS

Details
Articlenumber	150.006.850
Basic specifications
model	HDB 90 ST
max. working pressure	720 / 72 (bar/Mpa)	10443 psi
Performance
max. spreading force	51 / 5.2 (kN/t)	11465 lbf
spreading stroke	40 mm	1.6 in
max. length excl. extension pieces	930 mm	36.6 in
max. length incl. extension pieces	1230 mm	48.4 in
max. pushing force	38 / 3.9 (kN/t)	8543 lbf
Dimensions, weight and temperature
weight, ready for use	10.8 kg	23.8 lb
dimensions (AxBxC)	760 x 300 x 85 mm	29.9 x 11.8 x 3.3 in

FEATURES

Powerful

Suitable for use on high-resistance, multiple lock, inward opening doors

Extremely fast and quiet operation

As fast as explosives, without flying debris
Opens a door in seconds
Pneumatic-hydraulic drive: no sound from the pump

Lightweight with compact dimensions

Carrying, installation and operation by one person; saves manpower
Limits risk of making noise by knocking into things

Push button on door opener for clamping it into door frame

Quick, quiet and easy installation

Remote operation

Choice between using mounted control on 2 m. / 79 in. hose (part of Door Blaster Pack) or the separate Wireless Control Set (radio range: 100 m. / 328 ft. clear line of sight)
To activate door opener from a distance
To quickly release door opener from a distance
Enhances operator safety
Repetitive use possible
No interruption of your operation
